Ultra Ethylux® Family

Ultra Ethylux®

Ultra Ethylux® High Density Polyethylene (HDPE) is one of the most widely utilized thermoplastics due to its relative low cost, light weight, toughness, resistance to a broad range of chemicals and low moisture absorption. Ultra Ethylux is made with HDPE resin that is FDA compliant for use in food contact and potable water applications. Contact your local Westlake Plastics representative for specific regulatory declarations.

Request Quote

Download Datasheet

Industry

Chemical Process

Engineering

Food Processing

Attributes

Shapes

Colors Available

Typical Properties

Download Data Sheet

Property	Test Standard	English Units	Metric Units
Mechanical
Flexural Modulus - 1% Secant	D790	225 kpsi	1,550 MPa
Tensile Elongation @ Break	D638	>400%	>400%
Tensile Strength @ Yield	D638	4.6 kpsi	32 MPa
Thermal
HDT @ 66 psi	D648	180 °F	82 °C
Physical
Specific Gravity	D792	> 0.960	> 0.960
*Data above is based on testing of injection molded test specimens

Sheet Sizing

Compression Sheet Sizing

96"L x 48"W

0.25" (6.35mm)

0.375" (9.53mm)

0.5" (12.7mm)

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.50" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.50" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.50" (88.9mm)

3.75" (95.25mm)

4" (101.6mm)

120"L x 48"W

0.25" (6.35mm)

0.375" (9.53mm)

0.5" (12.7mm)

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.50" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.50" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.50" (88.9mm)

3.75" (95.25mm)

4" (101.6mm)

120"L x 60"W

0.375" (9.53mm)

0.5" (12.7mm)

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.50" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.50" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.50" (88.9mm)

3.75" (95.25mm)

4" (101.6mm)
