Ardel™

Ardel™ PAR polyarylate is a transparent, light-amber colored polymer that exhibits good toughness, superior optical and mechanical properties, exceptional UV stability, and excellent flexural fatigue resistance. Ardel™ PAR is specifically formulated to endure the damaging effects of UV light. When exposed to UV light, this unique material undergoes a molecular rearrangement resulting in the formation of a protective layer that essentially serves as a UV stabilizer. Ardel™ PAR is recommended for semiconductor components, solar energy components, appliance parts, and snap lock connectors.

Request Quote

Download Datasheet

Industry

Engineering

Semiconductor and ESD

Attributes

Shapes

Colors Available

Typical Properties

Download Data Sheet

Property	Test Standard	English Units	Metric Units
Mechanical
Flexural modulus	D790	304 kpsi	2100 MPa
Flexural Strength - 5%	D790	12 kpsi	84 MPa
Izod Impact, notched	D256	4.22 ft-lb/in	225 J/m
Moisture Absorption	D570	0.26 %	0.26 %
Specific Gravity	D792	1.21	1.21
Tensile Elongation @ Break	D638	60 %	60 %
Tensile Strength @ Break	D638	10 kpsi	69 MPa
Thermal
HDT @ 264 psi	D648	347 °F	175 °C
Electrical
Volume Resistivity	D257	333,333 ohm/sq (ft)	101,600 ohm/sq (m)

Sheet Sizing

Film Sizing

Slab Sizing

" Length by 24" Width

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

Extruded Sheet Sizing

96" Length by 48" Width

0.03" (0.76mm)

0.035" (0.89mm)

0.06" (1.52mm)

0.062" (1.57mm)

0.08" (2.03mm)

0.09" (2.29mm)

0.095" (2.41mm)

0.125" (3.18mm)

0.1875" (4.76mm)

0.25" (6.35mm)

26" Width

0.002" (0.05mm)

0.003" (0.08mm)

0.004" (0.1mm)

0.005" (0.13mm)

0.010" (0.25mm)

0.020" (0.51mm)
