Styraclear® Family
Styraclear®
Styraclear is made from resin that is suitable for use in certain food contact applications, contact your local Westlake Plastics representative for specific regulatory declarations. Styraclear is a rigid plastic that is often used in products that require clarity, such as food packaging and laboratory ware. Styraclear is a cost-effective, versatile thermoplastic that is known for being lightweight and easy to print on. For this reason, it is a great choice for POP display and indoor signage, among other common displays.
Industry
Attributes
Colors Available
Typical Properties
Download Data Sheet | Property | Test Standard | English Units | Metric Units |
| Mechanical | |||
| Flexural Modulus | D790 | 470 kpsi | 3,241 MPa |
| Flexural Strength - 5% | D790 | 13 kpsi | 90 MPa |
| Izod Impact Resistance - Notched | D256 | 0.40 ft·lb/in | 0.021 kJ/m |
| Tensile Elongation @ Break | D638 | 3.00 % | 3.00 % |
| Tensile Modulus | D638 | 460 kpsi | 3,172 MPa |
| Tensile Strength @ Break | D638 | 7.5 kpsi | 52 MPa |
| Tensile Strength @ Yield | D638 | 7.5 kpsi | 52 MPa |
| Thermal | |||
| HDT @ 264 psi | D648 | 192 °F | 89 °C |
| HDT @ 64 psi | D648 | 208 °F | 98 °C |
| Physical | |||
| Specific Gravity | D792 | 1.04 | 1.04 |
| *Data above is based on testing of injection molded test specimens | |||
Rod Sizing
Sheet Sizing
Compression Sheet Sizing
Documentation
No documents found.
Similar Products
No products found in this family
