Propylux® Family
Propylux® CN-P
Propylux™ PP CN-P (Statically conductive polypropylene) is a carbon powder-filled polypropylene offering surface resistivity in the 10e4 to 10e6 ohm/sq range and broad chemical resistance. This material is a good choice when ESD protection is needed or to minimize static discharge in flammable environments.
Industry
Attributes
Colors Available
Typical Properties
Download Data Sheet | Property | Test Standard | English Units | Metric Units |
| Mechanical | |||
| Tensile Strength - Yield | ASTM D638 | 3,050 psi | 21 Mpa |
| Tensile Strength - Break | ASTM D638 | 2,320 psi | 16 Mpa |
| Tensile Elongation - Yield | ASTM D638 | 8.4 % | 8.4 % |
| Tensile Elongation - Break | ASTM D638 | 48 % | 48 % |
| Tensile Modulus | ASTM D638 | 181,000 psi | 1,250 Mpa |
| Flexural Strength | ASTM D790 | 4,210 psi | 29 Mpa |
| Flexural Modulus | ASTM D790 | 170,000 psi | 1,170 Mpa |
| Izod Impact Resistance - Notched | ASTM D256 | 15 ft-lb/in | 0.8 kJ/m |
| Izod Impact Resistance - Unnotched | ASTM D4812 | no break ft-lb/in | no break kJ/m |
| Thermal | |||
| HDT @ 264 psi | ASTM D648 | 124°F | 51°C |
| Physical | |||
| Specific Gravity | ASTM D792 | 0.95 | 0.95 |
| Electrical | |||
| Surface Resistivity | ASTM D257 | 10² - 10⁶ ohm/sq | 10² - 10⁶ ohm/sq |
| *Data above is based on testing of injection molded test specimens | |||
Sheet Sizing
Compression Sheet Sizing
Documentation
No documents found.
