Propylux® SD-A - Westlake Plastics

Typical Properties

Property	Test Standard	English Units	Metric Units
Mechanical
Tensile Strength - Yield	ASTM D638	4,060 psi	28 Mpa
Tensile Elongation - Yield	ASTM D638	9.6 %	9.6 %
Tensile Elongation - Break	ASTM D638	47 %	47 %
Tensile Modulus	ASTM D638	202,000 psi	1,390 Mpa
Flexural Strength	ASTM D790	5,800 psi	40 Mpa
Flexural Modulus	ASTM D790	209,000 psi	1,440 Mpa
Izod Impact Resistance - Notched	ASTM D256	1.3 ft-lb/in	0.069 kJ/m
Izod Impact Resistance - Unnotched	ASTM D4812	no break ft-lb/in	no break kJ/m
Thermal
HDT @ 64 psi	ASTM D648	212°F	100°C
HDT @ 264 psi	ASTM D648	133°F	56°C
Physical
Moisture Absorption	ASTM D570	0.85 %	0.85 %
Specific Gravity	D792	0.952	0.952
Electrical
Surface Resistivity	D257	10⁹ - 10¹¹	10⁹ - 10¹¹
Volume Resistivity	D257	32,918.40 ohm-ft	1,080.00 ohm-cm
*Data above is based on testing of injection molded test specimens

Sheet Sizing

Slab Sizing

48"L x 24"W

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.5" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.5" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.5" (88.9mm)

3.75" (95.25mm)

4.0" (101.6mm)

Compression Sheet Sizing

48"L x 24"W

0.25" (6.35mm)

0.375" (9.53mm)

0.5" (12.7mm)

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.50" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.50" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.50" (88.9mm)

3.75" (95.25mm)

4" (101.6mm)

96"L x 48"W

0.25" (6.35mm)

0.375" (9.53mm)

0.5" (12.7mm)

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.50" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.50" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.50" (88.9mm)

3.75" (95.25mm)

4" (101.6mm)

120"L x 48"W

0.25" (6.35mm)

0.375" (9.53mm)

0.5" (12.7mm)

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.50" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.50" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.50" (88.9mm)

3.75" (95.25mm)

4" (101.6mm)

120"L x 60"W

0.25" (6.35mm)

0.375" (9.53mm)

0.5" (12.7mm)

0.75" (19.05mm)

1" (25.4mm)

1.25" (31.75mm)

1.50" (38.1mm)

1.75" (44.45mm)

2" (50.8mm)

2.25" (57.15mm)

2.50" (63.5mm)

2.75" (69.85mm)

3" (76.2mm)

3.25" (82.55mm)

3.50" (88.9mm)

3.75" (95.25mm)

4" (101.6mm)

Extruded Sheet Sizing

Sheet Width: 48 in. (width is untrimmed). Full width is 50 in.+ Useable width inside the edge bead is at least 48 in
Sheet Length: 96in L +0.25/-0.00 in)
"Finish: Polish/Matte (P/M) for sheets less the 0.060""T
Finish: Polish/Polish(P/P) for sheets 0.060""T and above"
Product supplied in sheet form is protected w/ low tack PE masking on both surfaces
Gauge Tolerance:
0.030 to 0.059 in = +/- 10%
0.060 to 0.099 in = +/- 0.005 in
0.100 to 0.125 in = +/- 0.007 in
0.126 to 0.200 in = +/-0.010 in
0.201 to 0.250 in = +/- 0.015 in
Product can be supplied in roll form. Material and gauge dependant, call for details
Non-standard gauges and sheet lengths can be offered on an MTO basis, call for details

96"L x 48"W

0.060" (1.52mm)

0.80" (20.32mm)

0.090" (2.29mm)

0.125" (3.18mm)

0.1875" (4.76mm)

0.250" (6.35mm)
